Katahdin

Introduction to Katahdin

In most programming languages you can define new functions and types. In the same way, Katahdin allows you to define new expressions, statements and other language constructs.

For example, most programming languages have a modulo, or remainder operator. If your language doesn’t have one, and there isn’t one that you can overload, creating one would involve learning about the internals of the implementation, modifying the grammar and adding semantic actions throughout the code base. You would then have to recompile and install your new implementation. Anyone else wanting to use it would have to be given a set of patches for your changes against the official implementation. In Katahdin, the complete syntax and semantics of the modulo operator can be defined from scratch in just a few lines:

class ModExpression : Expression {
    pattern {
        option leftRecursive;
        a:Expression "%" b:Expression
    }

    method Get() {
        a = this.a.Get...();
        b = this.a.Get...();
        return a - (b * (a / b));
    }
}

In Katahdin this is a runtime operation, so immediately after defining ModExpression the modulo operator becomes part of the language in line with all the other operators. You can define a new construct on one line and use it on the next.

There are no special constructs in Katahdin that cannot be modified, including white-space and basic tokens. If all of the constructs in a language are defined as above, Katahdin can be turned into an interpreter for that language. In this way, Katahdin can be used as a generic interpreter for any language, or one language can be used from within another by composing the two or more definitions. My implementation includes proof-of-concept language definitions for FORTRAN and Python, which can be composed to write a single program with a mix of the two languages.

import "fortran.kat";
import "python.kat";

fortran {
    SUBROUTINE RANDOM(SEED, RANDX)
        INTEGER SEED
        REAL RANDX
        SEED = 2045*SEED + 1
        SEED = SEED - (SEED/1048576)*1048576
        RANDX = REAL(SEED + 1)/1048577.0
        RETURN
    END
}

python {
    seed = 128
    randx = 0
    for n in range(5):
        RANDOM(seed, randx)
        print randx
}

There are real world scenarios where one would want to use one language from within another. People use SQL from within other languages all the time by writing the SQL in strings. In Katahdin, the definition of SQL can be composed with the main language and used as if it were all part of one language. There are also good examples of why one would want to define new constructs in a running program. For example, Java 1.5 included a new for-each-statement. Programmers wanting to use the statement had to wait for Sun’s implementation to be drafted, implemented, tested and distributed. In Katahdin programmers can create new statements on their own as they need them, without modifying the implementation. If you want a new for-each-statement in your language you can add one in a minute.

If you’ve got time, read the whole thesis.

Source Code

The Katahdin source code has been put into the public domain and packaged as katahdin-0.2.tar.gz. This 0.2 release included a couple of errors that were basically typos from the version I submitted as by thesis. It can be used for any purpose, in combination with any license.

Citations

E. Silkensen. Extensible syntax. Bachelor’s thesis, 2011.

Z. Porkoláb and Á. Sinkovics. Domain-specific language integration with compile-time parser generator library. In GPCE, 2010.

L. Tratt. Direct left-recursive parsing expression grammars. Technical report, Middlesex University, 2010.

L. Renggli, T. Gîrba, and O. Nierstrasz. Embedding languages without breaking tools. In European Conference on Object-Oriented Programming, 2010.

R. Knöll and M. Mezini. π - a pattern language. In OOPSLA, 2009.

E. Allen, R. Culpepper, J. D. Nielsen, J. Rafkind, and S. Ryu. Growing a syntax. In FOOL, 2009.

J. D. Nielsen. Languages for Secure Multiparty Computation and Towards Strongly Typed Macros. PhD thesis, University of Aarhus, 2009.

L. Renggli, M. Denker, and O. Nierstrasz. Language boxes - bending the host language with modular language changesguage boxes - bending the host language with modular language changesending the host language bending the host language with modular language changes. In Software Language Engineering, pages 274–293. Springer, 2009.

Pfront: a language with extensible syntax. Technical report, Meta Alternative Ltd., 2009.

S. Erdweg, T. Rendel, C. Kästner, and K. Ostermann. Sugarj: Library-based syntactic language extensibility. 2001.

Websites and Discussions

Bryan Ford’s Packrat Parsing and Parsing Expression Grammars Page

A Russian Wikipedia article about Katahdin, and translated into English (article not written by myself).

Lambda the Ultimate - Katahdin: Modifying your programming language as it runs and other discussions [1] [2] [3] [4] [5] [6] [7].

Y Combinator Hacker News article and discussion.

Yukihiro Matsumoto’s (designer of the Rugy language) blog post referring to Katahdin, and (poorly) translated into English.

A blog post by Armin Sander referring to my left recursion algorithm.
